2:1 Heat Shrink Mini Reel - Various Colours

2:1 Heat Shrink Mini Reel - Various Colours

Colour
Size
Regular price £4.99 GBP
Regular price Sale price £4.99 GBP
Sale Sold out
Quantity

Heat Shrink Mini Reel

  • 2:1 Ratio
  • UL Approved - UL 224 VW-1
  • Excellent Flexibility and Insulation
  • Superior Flame Retardant Properties
  • Available in the following colours: Black, Blue, White, Brown, Yellow, Grey Red, Yellow, Green, Clear
  • Please choose colour required when placing order
Size Before Shrink Size After Shrink Reel Length
1.6mm 1mm 15m
2.4mm 1.2mm 13M
3.2mm 1.6mm 12M
4.8mm 2.4mm 11M

6.4mm 3.2mm 10M
9.5mm 4.8mm 7M
12.7mm 6.4mm 6M
19mm 9.5mm 5M
25mm 12.5mm 4M



Technical Data:

Material: Polyolefin
Operating Range: -55 to +125 Degrees Celsius
Flammability: VW-1
UL, RoHS, Halogen Free

Description:
Heat Shrink Mini-Reel is a halogen-free, flexible, flame-retardant polyolefin shrinkable tubing.  It is low smoke generating, abrasion resistant and in case of burning produces no dioxin.  It has excellent electrical and physical properties, including advanced acid fastness and corrosion resistance.  This Heat Shrink is suitable for insulation use in automotive electronics, terminal lugs, small electrical parts and lead wires of toy motors and transformers etc.
